Helmet Visor Impact Testing Machine
Product Details:
- Product Type Helmet Visor Impact Testing Machine
- Power Supply Electric
- Voltage 220V Volt (v)
- Power 1 HP Horsepower (HP)
- Control Mode Automatic
- Click to View more
X
Helmet Visor Impact Testing Machine Price And Quantity
- 1 Unit
Helmet Visor Impact Testing Machine Product Specifications
- Automatic
- 1 HP Horsepower (HP)
- Electric
- 220V Volt (v)
- Helmet Visor Impact Testing Machine
Helmet Visor Impact Testing Machine Trade Information
- Cash in Advance (CID)
- 10 Unit Per Month
- 5-7 Days
- All India
Product Description
Standard Accessories and Parts
- Structure Aluminum 4040 and 4080;
- Digital display controller;
- Head form stand;
- Dividing ruler;
- Soft steel wire;
- Pulleyl;
- Hand wheel;
- Aluminum head;
- Penetrate carrier with electromagnetic;
- Tool for installation;
- Installation tool
- EN960 other models of head (aluminum)
Feature
- Equipped with sturdy and smooth slideway;
- Frame is made of aluminum structure material and steel base;
- Button controls the penetration cone release;
- Manual control of the rise and fall of the penetrating cone;
- The accuracy is highly displayed to 1mm;
Parameter
| Model | T003 |
| Falling height of penetrating head | 1000mm 5mm ( zero automatically ) |
| Impact tip weight | 300g 10g |
| Impact tip shape | Cone angle600,5 Head radius0.5mm0.1mm |
| The distance of impact tip above the head form | 10mm |
| Falling mass | 3.00kg 0.025kg |
| Height reading mode | Electronic encoder Indicator and dividing ruler |
| Head form | Aluminum, made according to EN960 (specific model required by customers) |
| Releasing by | Dc 24 electromagnetic chuck |
| Power Supply | 1Phase, 220V 50/60Hz |
