UE12XX Digital Electronic Tensile Testing Machine
Product Details:
- Dimension (L*W*H) 6004201500 Millimeter (mm)
- Speed Range 1%
- Power 220V Volt (v)
- Application Tensile Testing
- Weight 300 Kilograms (kg)
- Product Type Digital Electronic Tensile Testing Machine
- Click to View more
X
UE12XX Digital Electronic Tensile Testing Machine Price And Quantity
- 1 Unit
UE12XX Digital Electronic Tensile Testing Machine Product Specifications
- 6004201500 Millimeter (mm)
- Tensile Testing
- 1%
- Digital Electronic Tensile Testing Machine
- 300 Kilograms (kg)
- 220V Volt (v)
UE12XX Digital Electronic Tensile Testing Machine Trade Information
- Cash in Advance (CID)
- 10 Unit Per Month
- 5-7 Days
- All India
Product Description
The UE12XX Digital Electronic Tensile Testing Machine is a high-precision equipment designed for tensile testing applications. With a speed range of 1%, it ensures accurate and reliable results. Its robust build can handle a weight of up to 300 kilograms (kg) and its compact dimensions of 6004201500 millimeter (mm) make it easy to store and maneuver. Powered by 220V Volt (v), this machine is suitable for use in a variety of industrial settings. Its advanced features make it an ideal choice for quality control, research, and development purposes.
Standard Accessories- Encoder installed, Load cell installed; Servo motor built in; Control card and display unit;
- Flat Tension Grip; Compression Plates; Installation tool and Cables.
- Strain gauge type Extensometer, Large deformation Extensometer;
- Computer interface and software; Computer, Windows Operation System, Printer
Parameter
Model | UE1201 | UE1202 | UE1205 | ||
Max testing Force (kN) | 1 | 2 | 5 | ||
Valid force measuring range | 2%-100% F.S | ||||
Accuracy of Force | ±1% of indicated value (±0.5% as special order) | ||||
Resolution of Force | 1/300000 | ||||
Resolution of crosshead displacement Measurement | 0.01 mm | ||||
Displacement Accuracy | ±1% | ||||
Speed range of Crosshead | 0.01-500mm/min (Max 1000mm/min as special order) | ||||
Speed Accuracy | ±1% | ||||
Valid tension testing space | 800 | 800 | 800 | ||
Compression testing space | 900 | 900 | 900 | ||
Valid width between columns | / | / | / | ||
Tension sample | Flat sample thickness(mm) | 0-20 | 0-20 | 0-20 | |
Round sample diameter(mm) | / | / | / | ||
Crosshead Move Range | 0-1100mm | ||||
Deformation Measurement | ±1% as optional part | ||||
Connect to PC | By interface and Ethernet cable as optional parts. | ||||
Drive type | Servo Motor with Ball Screw Driver | ||||
Power supply | 1P, 220V, 50/60Hz | ||||
Overall dimension of host machine (mm) | 600×420×1500 | 600×420×1500 | 600×420×1500 | ||
Weight (kg) | 300 | 300 | 300 | ||
FAQs of UE12XX Digital Electronic Tensile Testing Machine:
Q: What is the maximum weight capacity of the UE12XX Tensile Testing Machine?
A: The UE12XX Tensile Testing Machine can handle a maximum weight of 300 kilograms (kg).Q: What is the speed range of the UE12XX Tensile Testing Machine?
A: The UE12XX Tensile Testing Machine has a speed range of 1%.Q: What is the power requirement for the UE12XX Tensile Testing Machine?
A: The UE12XX Tensile Testing Machine requires a power supply of 220V Volt (v).Q: What are the dimensions of the UE12XX Tensile Testing Machine?
A: The UE12XX Tensile Testing Machine has compact dimensions of 6004201500 millimeter (mm).Q: What applications is the UE12XX Tensile Testing Machine suitable for?
A: The UE12XX Tensile Testing Machine is suitable for a range of industrial applications including quality control, research, and development purposes.Enter Buying Requirement Details
