UH53XX Hydraulic Universal Testing Machine
Product Details:
- Application For static and dynamic testing of materials and components
- Power 220V Volt (v)
- Product Type Universal Testing Machine
- Dimension (L*W*H) 950x630x2265 Millimeter (mm)
- Weight 2700 Kilograms (kg)
- Speed Range 0.8r/min
- Click to View more
X
UH53XX Hydraulic Universal Testing Machine Price And Quantity
- 1 Unit
UH53XX Hydraulic Universal Testing Machine Product Specifications
- 2700 Kilograms (kg)
- 0.8r/min
- Universal Testing Machine
- For static and dynamic testing of materials and components
- 220V Volt (v)
- 950x630x2265 Millimeter (mm)
UH53XX Hydraulic Universal Testing Machine Trade Information
- Cash in Advance (CID)
- 10 Unit Per Month
- 5-7 Days
- All India
Product Description
The UH53XX Hydraulic Universal Testing Machine is a highly efficient testing machine designed for both static and dynamic testing of materials and components. With a speed range of 0.8r/min, this machine can effectively test a wide range of materials and components with precision and accuracy. The machine is designed with a weight of 2700 kilograms (kg) which makes it highly stable and durable. Its power input of 220V Volt (v) ensures that it can handle high capacity loads and perform consistently. The UH53XX Hydraulic Universal Testing Machine is ideal for use in research and development, quality control, and production environments. Its compact design with dimensions of 950x630x2265 Millimeter (mm) makes it easy to install and operate.
Accessories
| Description | UH52xxx Series |
| Standard Accessories | PC, Printer Extensometer, Displacement Encoder Hydraulic Pressure Sensor, Tension Test Accessories, Compression Test Accessories, 3-Points Bending Test Accessories |
| Optional Accessories | Shearing Test Accessories, Others according to order |
Mail feature
- This machine adopts oil cylinder on bottom type structure, hydraulic load, hydraulic clamping specimen.
- Oil Clearance sealing instead of O-ring sealing. Keep the cylinder loading stable and maintenance-free.
- Manually hydraulic valves loading control, give the high efficiency of common test.
- Load Capacity from 300KN to 2000KN.
- UH53xxx series Computer indicating and analyzing value result with monitor all kinds of Curve of load, displacement and deformation.
Parameter
| Model | UH5330 | UH5360 | UH53100 | UH53200 | |
| Measuring range of force(kN) | 6-300kN | 12-600kN | 20-1000kN | 40-2000KN | |
| Accuracy | 1% of indicated value | ||||
| Subsection of force | 1,2,5 for Dial type or No grade by Digital and Computer | ||||
| Tracing Plate speed | 0.4r/min, 0.8r/min, 2r/min for Dial type | ||||
| Clamping diameter for round specimen(mm) | 10-32 | 14-40 | 14-60 | 20-70 | |
| Clamping width of flat specimen | 70 mm | 75 mm | 80 mm | 110mm | |
| Clamping thickness of flat specimen(mm) | 0-15 | 0-30 | 0-40 | 0-60 | |
| Testing space | Tension | 620mm | 650mm | 650mm | 900mm |
| Compression | 550mm | 550mm | 550mm | 750mm | |
| Compression Platen size(mm) | 120 | 170x170 | 200x200 | 200x200 | |
| Distance of bending by pass roll(mm) | 60-320 | 100-450 | 100-450 | 100-500 | |
| Piston stroke | 200mm | ||||
| Power supply | 380/220v10%, 50/60Hz, 3 phase | ||||
| Working environment | Room temperature 1030,relative humidity80% | ||||
| Overall dimension(mm) | Host machine | 800x500x1950 | 950x630x2265 | 980x650x2450 | 1250x850x2800 |
| Dynomometer | 1070x810x1730 | 1070x810x1730 | 1070x810x1730 | 1070x810x1730 | |
| Weight(Kg) | 2100 | 2700 | 3500 | 7000 | |
FAQs of UH53XX Hydraulic Universal Testing Machine:
Q: What is the weight of the UH53XX Hydraulic Universal Testing Machine?
A: The weight of the UH53XX Hydraulic Universal Testing Machine is 2700 kilograms (kg).Q: What is the speed range of the UH53XX Hydraulic Universal Testing Machine?
A: The speed range of the UH53XX Hydraulic Universal Testing Machine is 0.8r/min.Q: What is the power input of the UH53XX Hydraulic Universal Testing Machine?
A: The power input of the UH53XX Hydraulic Universal Testing Machine is 220V Volt (v).Q: What is the application of the UH53XX Hydraulic Universal Testing Machine?
A: The UH53XX Hydraulic Universal Testing Machine is designed for both static and dynamic testing of materials and components.Q: What are the dimensions of the UH53XX Hydraulic Universal Testing Machine?
A: The dimensions of the UH53XX Hydraulic Universal Testing Machine are 950x630x2265 Millimeter (mm).Enter Buying Requirement Details
