Fatigue Dynamic Testing Machine

The Fatigue Dynamic Testing Machine is a state-of-the-art equipment that is designed to test the durability and strength of various mechanical components such as engines, electric actuators, servo motors, electric cylinders, computers, and software, among others. The machine comes with a speed range of up to 1000 RPM, making it ideal for testing components that require high-speed rotation. With its compact dimension of 800x100 millimeters and weight of 61 kilograms, the machine can be easily transported and used in different testing environments. It operates on a power supply of 220 volts that ensures its reliability and efficiency during testing. This machine is best suited for manufacturing plants, research and development departments, and quality assurance teams that require precise and accurate testing of their mechanical components.

Key specifications:

 Main feature

Host Framework

• Main frame of two columns, hard chrome plated, effective width between columns 500mm;
• Upper beam: The ball screw on the back of the column moves up and down to adjust the test space;
• The maximum adjustable space: 800mm;
• Working table height: 100mm;
• Frame stiffness: 3.3*108N/m.

2: Actuator

• Placed above the main frame workbench;
• Maximum static test force: +/-3kN;
• Maximum dynamic test force: +/-3kN;
• Actuator stroke: 150mm (can be customized).

3. Sensor

• High precision load sensor, placed on the upper beam, with pre-tensioning mechanism;
• Displacement sensor: Measuring range 150mm, built-in actuator.

4. Control and Computer Software System

• The control system uses Panasonic actuator; Test Control Software System;
• The test software is intuitive and readable.
