UE22XX Digital Electronic Tensile Testing Machine
Product Details:
- Application Tensile Testing
- Power 220V Volt (v)
- Speed Range 1%
- Weight 550 Kilograms (kg)
- Product Type Digital Electronic Tensile Testing Machine
- Dimension (L*W*H) 7406001800 Millimeter (mm)
- Click to View more
X
UE22XX Digital Electronic Tensile Testing Machine Price And Quantity
- 1 Unit
UE22XX Digital Electronic Tensile Testing Machine Product Specifications
- Tensile Testing
- 220V Volt (v)
- 1%
- Digital Electronic Tensile Testing Machine
- 7406001800 Millimeter (mm)
- 550 Kilograms (kg)
UE22XX Digital Electronic Tensile Testing Machine Trade Information
- Cash in Advance (CID)
- 10 Unit Per Month
- 5-7 Days
- All India
Product Description
The UE22XX Digital Electronic Tensile Testing Machine is designed for testing the tensile strength of various materials. With a power supply of 220V, this machine has a weight of 550kg and a speed range of 1%. Its dimensions are 7406001800mm, making it compact and easy to use. This machine is suitable for use in industries such as plastics, textiles, rubber, and metals. It can also be used for research and development purposes. The UE22XX Digital Electronic Tensile Testing Machine is a reliable and accurate tool for measuring the tensile strength of materials.
Standard Accessories- Encoder installed, Load cell installed; Servo motor built in; Control card and display unit;
- Flat Tension Grip; Compression Plates; Installation tool and Cables.
- Strain gauge type Extensometer, Large deformation Extensometer;
- Computer interface and software; Computer, Windows Operation System, Printer
Model | UE2201 | UE2202 | UE2210 | UE2220 | ||
Max testing Force (kN) | 1 | 2 | 10 | 20 | ||
Valid force measuring range | 2%-100% F.S | |||||
Accuracy of Force | ±1% of indicated value (±0.5% as special order) | |||||
Resolution of Force | 1/300000 | |||||
Resolution of crosshead displacement Measurement | 0.01 mm | |||||
Displacement Accuracy | ±1% | |||||
Speed range of Crosshead | 0.01-500mm/min (Max 1000mm/min as special order) | |||||
Speed Accuracy | ±1% |
|
| |||
Valid tension testing space | 800 | 800 | 800 | 800 | ||
Compression testing space | 900 | 900 | 900 | 900 | ||
Valid width between columns | 400 | 400 | 400 | 400 | ||
Tension sample | Flat sample thickness(mm) | 0-14 | 0-14 | 0-14 | 0-14 | |
Round sample diameter(mm) | Ø4-14 | Ø4-14 | Ø4-14 | Ø4-14 | ||
Crosshead Move Range | 0-1100mm | |||||
Deformation Measurement | ±1% as optional part | |||||
Connect to PC | By interface and Ethernet cable as optional parts. | |||||
Drive type | Servo Motor with Ball Screw Driver | |||||
Power supply | 1P, 220V, 50/60Hz | |||||
Overall dimension of host machine (mm) | 740×600×1800 | 740×600×1800 | 740×600×1800 | 740×600×1800 | ||
Weight (kg) | 550 | 550 | 550 | 550 | ||
FAQs of UE22XX Digital Electronic Tensile Testing Machine:
Q: What is the UE22XX Digital Electronic Tensile Testing Machine used for?
A: This machine is used for testing the tensile strength of various materials such as plastics, textiles, rubber, and metals.Q: What is the power supply for this machine?
A: The UE22XX Digital Electronic Tensile Testing Machine has a power supply of 220V.Q: What is the weight of the UE22XX Digital Electronic Tensile Testing Machine?
A: The machine has a weight of 550kg.Q: What is the speed range of the UE22XX Digital Electronic Tensile Testing Machine?
A: The machine has a speed range of 1%.Q: What are the dimensions of the UE22XX Digital Electronic Tensile Testing Machine?
A: The machine has dimensions of 7406001800mm.Enter Buying Requirement Details
