Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor
2000.00 - 20000.00 USD ($)
Product Details:
- Condition New
- Product Type Lab-scale continuous flow reactor
- General Use chemical research
- Material Other
- Capacity 0.6 Kg/hr
- Computerized No
- Automatic No
- Click to View more
X
Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor Price And Quantity
- 2000.00 - 20000.00 USD ($)
- 1 Unit
Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor Product Specifications
- Lab-scale continuous flow reactor
- Other
- New
- 1 year
- 0.6 Kg/hr
- No
- Other
- chemical research
- Yes
- No
Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor Trade Information
- Telegraphic Transfer (T/T)
- 10 Unit Per Month
- 1 Months
- All India
Product Description
Summary
CM-T series glass microchannel reactors have the characteristics of low reagent consumption (liquid holding capacity of microliters), large specific surface area, high temperature resistance (-25195), high pressure resistance (2Mpa), etc. The product takes into account the two major factors of mass transfer and pressure drop. There is no sudden shrinkage and sudden expansion in the process flow channel, which ensures efficient mass transfer and small pressure drop. The heat exchange module can maximize the mass transfer and heat transfer efficiency. Safely and stably realize the chemical process of research and development and small-scale trials.
CM-T glass flow microchannel reactor technical characteristics
More than 4 optional structural designs to meet the needs of most working conditions.
Glass material, high temperature resistance, compatible with all reagents except hot concentrated strong alkali, molten alkali metal, hot concentrated H3PO4, HF, and strong corrosive agents, and can run stably for a long time.
High temperature and high pressure resistance, the maximum pressure can reach 7Mpa (customized products).
visualization, each module can be directly observed or photographed independently - the observation window can be used to directly observe the process conditions or to photograph fluids with a microscope.
Photochemical reaction - the window can use LED or mercury lamp to realize photocatalytic process (by adding LED or mercury lamp light source module, photocatalytic reaction can be realized).
Equipped with a heat exchange module - it can realize the overall temperature control of the reaction (applicable to 4 modules) or dual temperature zone temperature control (applicable to 8 modules).
Good heat transfer and mass transfer performance, multiple static mixing unit structures in one piece to achieve efficient mixing.
Specifications
|
CM-T Lab-scale Continuous Flow Microchannel Reactors |
||||
|
Model |
CM-T-MSU |
CM-T-MSS |
CM-T-M(SV) |
CM-T-M(SX) |
|
Volume |
336uL |
257uL |
107uL |
119uL |
|
Channel Length |
1.58m |
2.32m |
4.82m |
1.71m |
|
Size |
50*80*4mm |
|||
|
Material |
glass |
|||
|
Temperature Range |
-25C-195C |
|||
|
Operating Pressure |
20bar(custom made up to 7Mpa) |
|||
|
Throughput |
0.1-10mL/minup to 0.6kg/h |
|||
|
Applicable reaction conditions |
The general-purpose microreactor is suitable for most reaction processes. The unique design enhances the mixing effect and speeds up the reaction rate. This structure is the same as our companys MF-V6 structure, and there is almost no amplification effect after the reaction transfer. |
General-purpose micro-reactor, suitable for most reaction processes. |
The process-enhanced micro-reactor has a good effect on the reaction where the two-phase density difference is large, the reaction rate constant is very low, and the fluid viscosity is small. |
The process-enhanced micro-reactor has a good effect on the reaction with a large difference in two-phase density and a very low reaction rate constant. |
|
Holder |
PFA/PPS |
|||
|
Reagent import and export |
Two in and one out or one in and one out (*Multiple imports can be customized) |
|||
|
Inert wetted materials |
PTFEPFA/PPSFFKMglass |
|||
FAQs of Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor:
Q: What is the capacity of Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor?
A: The capacity of this product is 0.6 Kg/hr.Q: Is Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor computerized?
A: No, this product is not computerized.Q: Can Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor be operated automatically?
A: No, this product cannot be operated automatically.Q: Is there any warranty period for Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor?
A: Yes, this product comes with a 1-year warranty.Q: What is the general use of Continuous Flow Microchannel Reactors/CM-T Series Lab-scale Glass Flow Reactor/Microfluidic reactor?
A: This product is suitable for chemical research purposes.Enter Buying Requirement Details
