HBS 3000 Brinell Hardness Tester
Product Details:
- Voltage 220V Volt (v)
- Product Type Brinell Hardness Tester
- Dimension (L*W*H) 893720470mm Millimeter (mm)
- Machine Weight 130kg Kilograms (kg)
- Control Mode Automatic
- Click to View more
X
HBS 3000 Brinell Hardness Tester Price And Quantity
- 1 Unit
HBS 3000 Brinell Hardness Tester Product Specifications
- 220V Volt (v)
- Brinell Hardness Tester
- 130kg Kilograms (kg)
- Automatic
- 893720470mm Millimeter (mm)
HBS 3000 Brinell Hardness Tester Trade Information
- Cash in Advance (CID)
- 10 Unit Per Month
- 5-7 Days
- All India
Product Description
Main feature
- Test force loading and unload motorized without heavy weight
- Adopts electronic auto loading Use 0.5% accuracy load sensor to feedback
- Microchip control system, automatically compensate the test force lost during testing
- Test force and load dwell time can be set on the touch-keyboard, reliable repetition, precise reading, and easy operation.
Parameter
| Description | HBE-3000 |
| Test force | 612.9N(62.5kgf), 980N(100kgf), 1226N(125kgf), 1839N(187.5kgf), 2452N(250kgf), 4900N(500kgf), 7355N(750kgf), 9800N(1000kgf), 14700N(1500kgf), 29400N(3000kgf) |
| Hardness measuring range | 8-650 HBW (Hard metals steel ball) |
| Hardness value Max. tolerance | 3%(HBW125) |
| Magnification of microscope | 20X |
| Min.division of microscopes drum wheel | 0.005mm |
| Max. height of specimens | 220mm |
| Max. width of specimens | 135mm |
| Power supply | 1P~AC220V, 50/60Hz |
| Package Dimensions (DWH) | 893720470mm |
| Gross weight | 160kg |
| Net weight | 130kg |
| Standard Accessories | Hard Alloyed Steel ball indenter:2.5510mm |
