Vickers Hardness Tester
Product Details:
- Usage Hardness Testing
- Dimension (L*W*H) 535mmX225mmX630mm Nanometer (nm)
- Voltage 220V Volt (v)
- Machine Weight 50KG Kilograms (kg)
- Control Mode Automatic
- Click to View more
X
Vickers Hardness Tester Price And Quantity
- 1 Unit
Vickers Hardness Tester Product Specifications
- 220V Volt (v)
- Automatic
- 50KG Kilograms (kg)
- 535mmX225mmX630mm Nanometer (nm)
- Hardness Testing
Vickers Hardness Tester Trade Information
- Cash in Advance (CID)
- 10 Unit Per Month
- 5-7 Days
- All India
Product Description
The Vickers Hardness Tester is a precision instrument that is used for hardness testing. With a dimension of 535mmX225mmX630mm, this machine is compact and easy to use. The machine weighs 50KG, which makes it easy to move around and store. The control mode of this machine is automatic, which ensures that the results are accurate and reliable. This machine works on a voltage of 220V Volt (v) and is suitable for use in various industries such as aerospace, automotive, and manufacturing. The Vickers Hardness Tester is designed to measure the hardness of materials by indenting the surface of the material with a diamond or carbide indenter. The indenter is pressed into the surface of the material with a known force, and the size of the indentation is measured. Hardness is calculated by dividing the force by the surface area of the indentation. This machine is ideal for use in quality control, research, and development, and can be used to test a wide range of materials, including metals, ceramics, and plastics.
Parameter
Model | HVM-5 | HVM-10 | HVM-30 | HVM-50 |
Test load(N) | 2.942/4.903/9.807 | 2.942/4.903/9.807 | 4.903/9.807/19.61/ | 9.807/19.61/24.52 |
Test load(Kgf) | 0.3 / 0.5/1 /2 / 2.5 /3 / 5 | 0.3 /0.5 /1 /2/2.5/ 3 / 5 / 10 | 0.5/ 1 / 2 / 2.5 | 1/ 2 / 2.5 / 3 |
Carriage control | Automatic (loading/dwell-time/unloading) | |||
Load holding time | 0~60 seconds | |||
Magnification of microscope | 100X, 400X | 100X, 400X | 100X,200X | 100X, 200X |
Microscope Min. measuring unit | 0.0625um(400X) 0.125um(200X) 0.250um(100X) | |||
Testing range | 1HV~2967HV | |||
Lens/indenter switch | HVS series with hand Turret, HVM series with motorized turret | |||
Hardness Scales | HVM whith function of convert HB,HRC,HRA,HRB,HRN,HRT, | |||
Dimension of XY table | 100X100mm | No | ||
Stroke of XY table | 25X25mm | No | ||
Max. height of specimen | 170mm | |||
Max. depth of specimen | 130mm | |||
Light source | Cold Light Source | |||
Power | 1P~110V/220V, 50/60HZ | |||
Objective | 10X, 20X and 40X can be selected according to users requirement | |||
Main | XY test table(HVS-5,HVS-10) | Large test table; V shape test table; | ||
10X Digital micro eyepiece ; Lever ; Adjustable screw; Vickers hardness block, RS232 Cable, Mini Printer | ||||
Option accessories | HVS series can choose Motorized Turret(HVS-Z); HVS, HVM can add CCD Video system(HV-CCD), | |||
Dimension | 535mmX225mmX630mm | |||
Weight | Gross weight:60KG; Net weight: 50KG | |||
FAQs of Vickers Hardness Tester:
Q: What is the Vickers Hardness Tester used for?
A: The Vickers Hardness Tester is used for hardness testing.Q: What is the dimension of the Vickers Hardness Tester?
A: The dimension of the Vickers Hardness Tester is 535mmX225mmX630mm.Q: What is the control mode of the Vickers Hardness Tester?
A: The control mode of the Vickers Hardness Tester is automatic.Q: What is the voltage of the Vickers Hardness Tester?
A: The voltage of the Vickers Hardness Tester is 220V Volt (v).Q: What is the weight of the Vickers Hardness Tester?
A: The weight of the Vickers Hardness Tester is 50KG Kilograms (kg).Enter Buying Requirement Details
